Important Notice:
1. Firstly check the circuitry connecting correctly or not before using the machine.
2. Before starting work, fill up the water-tank with distilled water from the Affusion Orifice.
3. Water must be distilled water or ion-wipe-off, not the mineral water or tap water.
4. Before using the machine, infuse the distilled water to the standard line on the water
tank. Prohibit to work without water. Otherwise, if shatter the laser head, the user bear it.
5. Avoid irradiation to eyes directly.
6. Forbid disassembling without manufacture permission.
7. Put the head light on fixture avoid broken after operation.
8. Change cooling water every month. (Long or short the time according to the water purity).
9.Start-up the machine after one minute later for the water circulation completely.
10. Ensure the machine well grounded.
Technical Specifications:
Type of laser: Solid-state Q-switch Nd:YAG laser
Wavelength: 1064nm, 532nm
Output Energy: 160mJ 350mJ 600mJ
Pulse duration: 8-10ns
Frequency: 1, 2, 3, 4, 5, 6Hz
Power supply: AC220V 50Hz
Power: 1500VA
Size: 490mm×290mm×300mm
Weight: 10kg
Application Range:
1. Remove the black &blue pigment on eyebrow, eye line and lip line.
Scour off tattoo, freckle, lentigines, old aged marks, vascular expansion and
type of blood vessel lesions etc.
2. No harm to the follicles and normal skin, leaving no scar, only to lustrate pigment.
3. To lustrate melanin not being eliminated by medicament and other means.
4. Be in no need of anesthesia and quick recovery. No negative influence
Product Features:
1. Improve the efficiency and make the best solutions for no burning on the hand-piece at all.
2. Long lifetime for Xenon Lamp which is with the imported US technology.
3. More stability with the hand-piece structure inside improved.
4. Add the infrared Guide light to aim the target tissue correctly.
5. Portable design and easy operation can do the touring treatment;
lower cost and wider usage can make quick return of investment.
Working Principle：
Laser emitted by the system has a strong penetration ability which allows it to reach the deep layer of dermis.
The pigment particles absorb the light energy and explode sharply,
burst into the tiny pieces, thus diminish the color density and get rid of it.
So the appliance can effectively do away with mutant pigmentations
and vascular tissue based on undamaged ambient tissue. This is called ‘
Selective heat absorption’ principle in medical field.
